Passed IS09001: 2000 quality management system and ISO/TSl6949: 2002 quality management system certification.
Bearing Type: deep groove ball bearing-single row radial ball bearing
Brand: HXB or OEM brand
Material: chrome steel GCr15, AISL52100, SUJ2
Part No.: 608-ZZ, 608Z, MR608ZZ,
Clearance: C2, CM, C0, C3
Noise & Vibration: ZV2,ZV3,ZV4
Precision Class: P0, P6, P5, ABEC-1, ABEC-3,ABEC-5
Lubrication: Kyodo Yushi, Chevron, Sinopec or others
Application: 608ZZ Metric Ball Bearings are used in a range of applications from skate board, electric power tool,motor, castor, ice skate, sliding rail.
The 608 is a 8 mm Ball Bearing that can be used in many rotary and factory automation applications. The 608 Miniature Ball Bearings is an open style bearing. The 608Z ball bearing is a single row raceway and single shielded. The 608ZZ ball bearing has a single row raceway and it is shielded on each side. The B608DDU, 608LLU, 608H2RS, 608-2RS ball bearing are shielded by two rubber seals on each side. The 608 8 mm Ball Bearing Inner Dimension 8mm X Outer Dimension 22mm X Width 7mm is an open style ball bearing designed for high rotational speeds and high dynamic loads.
Bearing Number | Boundary dimensions(mm) | Load Rating(KN) | Limiting Speed(rpm) | Weight(kg) | |||||
d | D | B | rmin | Cr | Cor | Grease | Oil | ||
6800 | 10 | 19 | 5 | 0.3 | 1.83 | 0.93 | 32000 | 38000 | 0.005 |
6900 | 22 | 6 | 0.3 | 2.70 | 1.27 | 30000 | 36000 | 0.011 | |
6000 | 26 | 8 | 0.3 | 4.55 | 1.96 | 29000 | 34000 | 0.019 | |
6200 | 30 | 9 | 0.6 | 5.10 | 2.39 | 25000 | 30000 | 0.032 | |
6300 | 35 | 11 | 0.6 | 8.20 | 3.50 | 23000 | 27000 | 0.052 | |
6801 | 12 | 21 | 5 | 0.3 | 1.92 | 1.04 | 29000 | 35000 | 0.007 |
6901 | 24 | 6 | 0.3 | 2.89 | 1.46 | 27000 | 32000 | 0.013 | |
16001 | 28 | 7 | 0.3 | 5.10 | 2.39 | 26000 | 30000 | 0.019 | |
6001 | 28 | 8 | 0.3 | 5.10 | 2.39 | 26000 | 30000 | 0.022 | |
6201 | 32 | 10 | 0.6 | 6.10 | 2.75 | 22000 | 26000 | 0.035 | |
6301 | 37 | 12 | 1.0 | 9.70 | 4.20 | 20000 | 24000 | 0.051 | |
6802 | 15 | 24 | 5 | 0.3 | 2.08 | 1.26 | 26000 | 31000 | 0.008 |
6902 | 28 | 7 | 0.3 | 4.10 | 2.06 | 24000 | 28000 | 0.018 | |
16002 | 32 | 8 | 0.3 | 5.60 | 2.84 | 22000 | 26000 | 0.025 | |
6002 | 32 | 9 | 0.3 | 5.60 | 2.84 | 22000 | 26000 | 0.031 | |
6202 | 35 | 11 | 0.6 | 7.75 | 3.60 | 19000 | 23000 | 0.045 | |
6302 | 42 | 13 | 1.0 | 11.40 | 5.45 | 17000 | 21000 | 0.080 | |
6803 | 17 | 26 | 5 | 0.3 | 2.81 | 1.72 | 24000 | 28000 | 0.008 |
6903 | 30 | 7 | 0.3 | 4.65 | 2.58 | 22000 | 26000 | 0.020 | |
16003 | 35 | 8 | 0.3 | 6.80 | 3.35 | 20000 | 24000 | 0.027 | |
6003 | 35 | 10 | 0.3 | 6.80 | 3.35 | 20000 | 24000 | 0.040 | |
6203 | 40 | 12 | 0.6 | 9.60 | 4.60 | 18000 | 21000 | 0.064 | |
6303 | 47 | 14 | 1.0 | 13.50 | 6.55 | 16000 | 19000 | 0.109 | |
6804 | 20 | 32 | 7 | 0.3 | 4.00 | 2.47 | 21000 | 25000 | 0.020 |
6904 | 37 | 9 | 0.3 | 6.40 | 3.70 | 19000 | 23000 | 0.040 | |
16004 | 42 | 8 | 0.3 | 7.90 | 4.50 | 18000 | 21000 | 0.050 | |
6004 | 42 | 12 | 0.6 | 9.40 | 5.05 | 18000 | 21000 | 0.068 | |
6204 | 47 | 14 | 1.0 | 12.80 | 6.65 | 16000 | 18000 | 0.103 | |
6304 | 52 | 15 | 1.1 | 15.90 | 7.90 | 14000 | 17000 | 0.142 | |
6805 | 25 | 37 | 7 | 0.3 | 4.30 | 2.95 | 18000 | 21000 | 0.022 |
6905 | 42 | 9 | 0.3 | 7.05 | 4.55 | 16000 | 19000 | 0.050 | |
16005 | 47 | 8 | 0.3 | 8.35 | 5.10 | 15000 | 18000 | 0.060 | |
6005 | 47 | 12 | 0.6 | 10.10 | 5.85 | 15000 | 18000 | 0.078 | |
6205 | 52 | 15 | 1.0 | 14.00 | 7.85 | 13000 | 15000 | 0.127 | |
6305 | 62 | 17 | 1.1 | 21.20 | 10.90 | 12000 | 14000 | 0.219 | |
6806 | 30 | 42 | 7 | 0.3 | 4.70 | 3.65 | 15000 | 18000 | 0.026 |
6906 | 47 | 9 | 0.3 | 7.25 | 5.00 | 14000 | 17000 | 0.060 | |
16006 | 55 | 9 | 0.3 | 11.20 | 7.35 | 13000 | 15000 | 0.085 | |
6006 | 55 | 13 | 1.0 | 13.20 | 8.30 | 13000 | 15000 | 0.110 | |
6206 | 62 | 16 | 1.0 | 19.50 | 11.30 | 11000 | 13000 | 0.200 | |
6306 | 72 | 19 | 1.1 | 26.70 | 15.00 | 10000 | 12000 | 0.349 | |
6807 | 35 | 47 | 7 | 0.3 | 4.90 | 4.05 | 13000 | 16000 | 0.030 |
6907 | 55 | 10 | 0.6 | 11.20 | 7.45 | 12000 | 15000 | 0.086 | |
16007 | 62 | 9 | 0.3 | 11.70 | 8.20 | 12000 | 14000 | 0.100 | |
6007 | 62 | 14 | 1.0 | 16.00 | 10.30 | 12000 | 14000 | 0.148 | |
6207 | 72 | 17 | 1.1 | 25.70 | 15.30 | 9800 | 11000 | 0.288 | |
6307 | 80 | 21 | 1.5 | 33.50 | 19.10 | 8800 | 10000 | 0.455 | |
6808 | 40 | 52 | 7 | 0.3 | 5.10 | 4.40 | 12000 | 14000 | 0.034 |
6908 | 62 | 12 | 0.6 | 14.60 | 10.20 | 11000 | 13000 | 0.110 | |
16008 | 68 | 9 | 0.3 | 12.60 | 9.65 | 10000 | 12000 | 0.130 | |
6008 | 68 | 15 | 1.0 | 16.80 | 11.50 | 10000 | 12000 | 0.185 | |
6208 | 80 | 18 | 1.1 | 29.10 | 17.80 | 8700 | 10000 | 0.368 | |
6308 | 90 | 23 | 1.5 | 40.50 | 24.00 | 7800 | 92000 | 0.639 | |
6809 | 45 | 58 | 7 | 0.3 | 6.40 | 5.65 | 11000 | 12000 | 0.010 |
6909 | 68 | 12 | 0.6 | 15.10 | 11.20 | 9800 | 12000 | 0.140 | |
16009 | 75 | 10 | 0.6 | 12.90 | 10.50 | 9200 | 11000 | 0.170 | |
6009 | 75 | 16 | 1.0 | 21.00 | 15.10 | 9200 | 11000 | 0.230 | |
6209 | 85 | 19 | 1.1 | 32.50 | 20.40 | 7800 | 9200 | 0.414 | |
6309 | 100 | 25 | 1.5 | 53.00 | 32.00 | 7000 | 8200 | 0.837 | |
6810 | 50 | 65 | 7 | 0.3 | 6.60 | 6.10 | 9600 | 11000 | 0.057 |
6910 | 72 | 12 | 0.6 | 15.60 | 12.20 | 8900 | 11000 | 0.140 | |
16010 | 80 | 10 | 0.6 | 13.20 | 11.30 | 8400 | 9800 | 0.180 | |
6010 | 80 | 16 | 1.0 | 21.80 | 16.60 | 8400 | 9800 | 0.258 | |
6210 | 90 | 20 | 1.1 | 35.00 | 23.20 | 7100 | 8300 | 0.463 | |
6310 | 110 | 27 | 2.0 | 62.00 | 38.50 | 6400 | 7500 | 1.082 | |
6811 | 55 | 72 | 9 | 0.3 | 8.80 | 8.10 | 8700 | 10000 | 0.080 |
6911 | 80 | 13 | 1.0 | 16.00 | 13.30 | 8200 | 9600 | 0.190 | |
16011 | 90 | 11 | 0.6 | 18.60 | 15.30 | 7700 | 9000 | 0.260 | |
6011 | 90 | 18 | 1.1 | 28.30 | 21.20 | 7700 | 9000 | 0.383 | |
6211 | 100 | 21 | 1.5 | 43.50 | 29.20 | 6400 | 7600 | 0.603 | |
6311 | 120 | 29 | 2.0 | 71.50 | 45.00 | 5800 | 6800 | 1.355 | |
6812 | 60 | 78 | 10 | 0.3 | 11.50 | 10.60 | 8000 | 9400 | 0.110 |
6912 | 85 | 13 | 1.0 | 16.40 | 14.30 | 7600 | 8900 | 0.230 | |
16012 | 95 | 11 | 0.6 | 20.00 | 17.50 | 7000 | 8300 | 0.280 | |
6012 | 95 | 18 | 1.1 | 29.50 | 23.20 | 7000 | 8300 | 0.391 | |
6212 | 110 | 22 | 1.5 | 52.50 | 36.00 | 6000 | 7000 | 0.780 | |
6312 | 130 | 31 | 2.1 | 82.00 | 52.00 | 5400 | 6300 | 1.710 | |
6813 | 65 | 85 | 10 | 0.6 | 11.60 | 11.00 | 7400 | 8700 | 0.130 |
6913 | 90 | 13 | 1.0 | 17.40 | 16.10 | 7000 | 8200 | 0.220 | |
16013 | 100 | 11 | 0.6 | 20.50 | 18.70 | 6500 | 7700 | 0.300 | |
6013 | 100 | 18 | 1.1 | 30.50 | 25.20 | 6500 | 7700 | 0.410 | |
6213 | 120 | 23 | 1.5 | 57.50 | 40.00 | 5500 | 6500 | 0.957 | |
6313 | 70 | 140 | 33 | 2.1 | 92.50 | 60.00 | 4900 | 5800 | 2.100 |
6814 | 90 | 10 | 0.6 | 12.10 | 11.90 | 6900 | 8100 | 0.114 | |
6914 | 100 | 16 | 1.0 | 23.70 | 21.20 | 6500 | 7700 | 0.350 | |
16014 | 110 | 13 | 0.6 | 24.40 | 22.60 | 6100 | 7100 | 0.430 | |
6014 | 110 | 20 | 1.1 | 38.00 | 31.00 | 6100 | 7100 | 0.575 | |
6214 | 125 | 24 | 1.5 | 62.00 | 44.00 | 5100 | 6000 | 1.100 | |
6314 | 150 | 35 | 2.1 | 104.00 | 68.00 | 4600 | 5400 | 2.550 |
